Home/Case Studies/Loxton Walk, London
Streetscape · Retail Mews · Cloud-Controlled RGBW

Loxton Walk

A canopy off Baker Street — 378 individually-addressable MaxiGlobe RGBW globes, catenary-hung with no poles, no columns.

Loxton Walk · off Baker Street · Marylebone · London · UK
Location
Loxton Walk — off Baker Street
Marylebone · London · UK
Specified by
Lawrence Hayes
LITE Architectural & MaxiLED
System
Turnkey — MaxiLED lighting
+ cloud-based show control
Overhead
378 MaxiGlobe RGBW with Batcap
individually addressable
Rigging
Catenary, facade-anchored
no poles · no columns
Installation
Field and Lawn
Corey Smith & Karl Roberts
Commissioning
Ryan Graham
& Alistair Fletcher
Photography · Drone
Ryan Graham
Now open to the public
Background

A new London mews, lit without a single pole.

Loxton Walk is a new pedestrian retail mews just off Baker Street in Marylebone — a paved walk lined with shopfronts, planters and café terraces, threaded between the surrounding buildings. Now commissioned and open to the public, the space is crowned by a dynamic canopy of MaxiLED festoon lighting that turns the entire walk into a single, slowly moving composition of colour.

The defining move of the installation is what is not there. There are no lighting columns and no poles anywhere in the walk. Every catenary wire is anchored directly into the building fabric on either side of the mews, so the canopy floats free above a completely clear ground plane — nothing interrupts the paving, the planting or the sightline to the arched entrance at the far end.

Across those catenaries run 378 MaxiGlobe RGBW globes with Batcap, every one individually addressable. Open rows of festoon span the length of the walk, gathering into a dense, closely-pitched grid of colour at the covered threshold — a ceiling of pixels over the entrance, behaving like a low-resolution video ceiling.

Show control lives in the cloud: full-field colour washes that travel down the walk, rainbow gradients that paint the paving, cool white star-field scenes and calm single-colour holds for everyday trading. Colourways and programmes can be scheduled, updated and re-themed for seasons and events remotely — without a ladder ever touching the site.

Loxton Walk · the RGBW canopy in motion
Daylight detail โ€” catenary wires and clear-lensed MaxiGlobe RGBW globes running straight off the brickwork and facade band, with no supporting structure โ€” Loxton Walk, London

“Now commissioned and open to the public… It’s a beauty. Want to see for yourself? Go — it’s open, and just off Baker Street.”

Lawrence Hayes · U.K. Specification Manager, LITE Architectural & MaxiLED
Specification note · No poles, no columns

Supported off the buildings — not off the street.

The entire canopy is supported off the buildings themselves — every catenary is fixed directly to the wall. For retail and mixed-use environments — malls, mews, laneways, courtyards — this removes the single biggest obstacle to overhead lighting: no streetscape clutter, no foundations, and no catenary poles to specify, buy or maintain. Along the open length of the walk the festoon reads as individual points of colour against the sky; toward the covered threshold the pitch tightens into a close-set grid at near-matrix density. Loxton Walk demonstrates the full turnkey model — specified by MaxiLED, installed by Field and Lawn, controlled entirely from the cloud.

System specified
Large Globe · Batcap · Data over Power
MaxiGlobe RGBW with Batcap

MaxiLED’s full-spectrum festoon globe — individually addressable, with power and data combined over a single two-core cable at 48 VDC. IP68 and IK07 rated for permanent outdoor installation, it supports long continuous runs (up to 100 globes per strand, 175 m max) and the synchronised, per-globe colour movement the Loxton Walk canopy is built on. Deployed here in its Batcap configuration with cloud-based show control.
